View In:   ArcGIS Online Map Viewer

Name: Sewer Atlas Grid

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="margin:0 0 0 0;"><SPAN><SPAN>This sewer atlas grid feature class was created for the purpose of displaying and associating sewer features to the grid numbers. Paper and scanned copies of each map in this sewer grid are maintained by the City of Sheboygan's DPW Engineering Division. The purpose of this digital feature class was to replace the paper copies that employees would have to reference to see what paper (or scanned) sewer atlas map they wanted to view to reference the sewer system in a particular area. </SPAN></SPAN></P><P /><P STYLE="margin:0 0 0 0;"><SPAN><SPAN>To create this feature class, the original CAD file was not usable because it contained no spatial reference. A paper printed copy of this grid map was scanned and georeferenced in ArcGIS Pro by andrew.bartell@sheboyganwi.gov and the grid polygons were manually drawn on the georeferenced image. Attributes were given for the corresponding grid numbers. A text string field was used for the "numbers" since many numbers contained preceding zeros and negative signs, which are problematic in GIS for displaying. </SPAN></SPAN></P><P /><P STYLE="margin:0 0 0 0;"><SPAN><SPAN>There is no update schedule for this data. This data should not be being updated in any other location other than this database. </SPAN></SPAN></P><P /><P STYLE="margin:0 0 0 0;"><SPAN><SPAN>The owner of this data is the DPW Engineering Department. Contact andrew.bartell@sheboyganwi.gov for more info. </SPAN></SPAN></P><P><SPAN>Date created 11/1/2018</SPAN></P></DIV></DIV></DIV>

Service Item Id: 927c8c7a0be94a2097d771986509176b

Copyright Text: City of Sheboygan, DPW Engineering Division

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 205773.6467938274
YMin: 155598.94550915807
XMax: 223803.68881766126
YMax: 191722.0517404899
Spatial Reference: 103458  (103458)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [223, 115, 255, 181]
Outline:
Style: esriSLSSolid
Color: [52, 52, 52, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• Name ( type: esriFieldTypeString, alias: Name, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Name )
• Number ( type: esriFieldTypeDouble, alias: Number, editable: true, nullable: true, defaultValue: null, modelName: Number )
• Type ( type: esriFieldTypeString, alias: Type, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Type )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Path ( type: esriFieldTypeString, alias: Path, editable: true, nullable: true, length: 500, defaultValue: null, modelName: Path )
• URL ( type: esriFieldTypeString, alias: URL, editable: true, nullable: true, length: 500, defaultValue: null, modelName: URL )
• Notes ( type: esriFieldTypeString, alias: Notes, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Notes )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• Shape__Area ( type: esriFieldTypeDouble, alias: SHAPE.STArea(), editable: false, nullable: false, defaultValue: null, modelName: SHAPE.STArea() )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: false, defaultValue: null, modelName: SHAPE.STLength() )

Templates:

• Name: Sewer Atlas Grid
  Description:
  Prototype:
  Notes: null
  Name: null
  Number: null
  Type: null
  URL: null
  Path: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Create,Update,Delete,Uploads,Editing,ChangeTracking

Sync Can Return Changes: true

Is Data Versioned: false

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: true

Supports ApplyEdits By Upload Id: true

Supports Query With Historic Moment: true

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Apply Edits   Add Features   Update Features   Delete Features   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
