Name: Pipes

Display Field: Size

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><P STYLE="font-size:16ptmargin:7 0 7 0;"><SPAN>This is a dataset of all storm and sanitary sewer pipes in the City of Sheboygan. This data originated from the 2017 legacy "Mobile MMS/Websoft". This dataset is continually being updated, and should be considered current and accurate. This dataset is considered the authoritative source for all storm and sanitary sewer pipes for the City of Sheboygan.</SPAN></P><P STYLE="font-size:16ptmargin:7 0 7 0;"><SPAN><SPAN>For additional information, please contact andrew.bartell@sheboyganwi.gov</SPAN></SPAN></P><DIV><P><SPAN /></P></DIV></DIV>

Service Item Id: 6e0b5dee06df452bbbdfdb6dbe2cf17b

Copyright Text: City of Sheboygan, Engineering Department

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 205767.32889308035
YMin: 151593.52569849044
XMax: 223435.06422682852
YMax: 191611.58739449084
Spatial Reference: 103458  (103458)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [112, 168, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• Size ( type: esriFieldTypeString, alias: Size (old), length: 254 )
• Material ( type: esriFieldTypeString, alias: Pipe Material, length: 254 , Coded Values: [Concrete: Concrete] , [Masonry: Masonry] , [PVC: PVC] , ...12 more... )
• Year ( type: esriFieldTypeDouble, alias: Installation Year )
• Inspector ( type: esriFieldTypeString, alias: Installation Inspector, length: 254 )
• Contractor ( type: esriFieldTypeString, alias: Installation Contractor, length: 254 )
• PlanNumber ( type: esriFieldTypeString, alias: Plan Number, length: 254 )
• Municipality ( type: esriFieldTypeString, alias: Municipality, length: 254 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 254 )
• Insp_Report ( type: esriFieldTypeString, alias: Inspection Report, length: 254 )
• Diameter_H ( type: esriFieldTypeInteger, alias: Diameter (Height) )
• Diameter_W ( type: esriFieldTypeInteger, alias: Diameter (width) )
• Status ( type: esriFieldTypeString, alias: Pipe Status, length: 50 , Coded Values: [ACTIVE: ACTIVE] , [ABANDONED: ABANDONED] , [REMOVED: REMOVED] , ...3 more... )
• Length_GIS ( type: esriFieldTypeDouble, alias: GIS Calculated Length )
• Pipe_ID ( type: esriFieldTypeString, alias: Pipe ID, length: 254 )
• From_MH ( type: esriFieldTypeString, alias: From Manhole, length: 254 )
• To_MH ( type: esriFieldTypeString, alias: To Manhole, length: 254 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• CreatedBy ( type: esriFieldTypeString, alias: Created By, length: 50 )
• CreatedDate ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• EditBy ( type: esriFieldTypeString, alias: Edit By, length: 50 )
• EditDate ( type: esriFieldTypeDate, alias: Edit Date, length: 8 )
• SewerAtlas ( type: esriFieldTypeString, alias: Sewer Atlas Number, length: 50 )
• LiningYear ( type: esriFieldTypeDouble, alias: LiningYear )
• LiningContractor ( type: esriFieldTypeString, alias: LiningContractor, length: 300 )
• System ( type: esriFieldTypeString, alias: System, length: 20 , Coded Values: [Storm: Storm] , [Sanitary: Sanitary] )
• Type ( type: esriFieldTypeString, alias: Storm System Type, length: 50 , Coded Values: [Underdrain: Underdrain] , [Private: Private] , [Outfall Lead: Outfall Lead] , ...7 more... )
• IE_Upstream ( type: esriFieldTypeDouble, alias: Invert Elevation (upstream) )
• IE_Downstream ( type: esriFieldTypeDouble, alias: Invert Elevation (downstream) )
• Slope ( type: esriFieldTypeDouble, alias: Slope )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• GUID ( type: esriFieldTypeGUID, alias: GUID, length: 38 )
• Measuredown_Upstream ( type: esriFieldTypeDouble, alias: DOWN Upstream )
• Measuredown_Downstream ( type: esriFieldTypeDouble, alias: DOWN Downstream )
• Condition ( type: esriFieldTypeString, alias: Condition, length: 50 , Coded Values: [Excellent: Excellent] , [Good: Good] , [Failing: Failing] , ...2 more... )
• ConditionDate ( type: esriFieldTypeDate, alias: Last Condition Date, length: 8 )
• ConditionNotes ( type: esriFieldTypeString, alias: Condition Notes, length: 255 )
• PipeShape ( type: esriFieldTypeString, alias: Pipe Shape, length: 50 , Coded Values: [Circular: Circular] , [Elliptical: Elliptical] , [Rectangular: Rectangular] )
• Manufacturer ( type: esriFieldTypeString, alias: Pipe Manufacturer, length: 100 )
• Video ( type: esriFieldTypeString, alias: Video Link, length: 255 )
• InstallationStart ( type: esriFieldTypeDate, alias: Installation Start Date, length: 8 )
• InstallationEnd ( type: esriFieldTypeDate, alias: Installation End Date, length: 8 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Jurisdiction ( type: esriFieldTypeString, alias: Jurisdiction, length: 255 , Coded Values: [Private: Private] , [City: City] , [Town: Town] )
• SanitaryArea ( type: esriFieldTypeString, alias: Sanitary Area, length: 255 )
• BoreThrough ( type: esriFieldTypeString, alias: Bore Through?, length: 255 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Relationships:

• SewerPipesWOs (2) -- Related To: Sewer Pipe Work Order (10)

Supported Operations:   Query   Query Attachments   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
